A reinforced concrete edge beam supports the adjacent floor slab with top and bottom beam reinforcing bars sized per the concrete beam schedule. Closed-type stirrups provide shear reinforcement throughout the beam depth and width per schedule spacing. Added horizontal bars are placed on each face as indicated in the typical concrete beam section. The slab top bars extend into and anchor within the edge beam assembly.
30" 18" SLAB TOP BARS BM TOP BARS, SEE "CONC BM SCHED" CLOSED TYPE STIRRUPS. SEE "CONC BM SCHED" FOR SIZE & SPACING BM BOT BARS SEE "CONC BM SCHED" ADDED HORIZ BARS EF, SEE "TYP CONC BM SECT & STIRRUPS" SEE "CONC BM SCHED" SEE "CONC BM SCHED" DEPTH WIDTH
