Cold-formed steel interior metal studs measuring 400S162-43 at 16 inches on center frame the light cove and linear diffuser assembly, secured with three number 10 sheet metal screws typically. A continuous 1-1/2 by 1-1/2 inch by 16-gauge angle attaches with a number 10 screw at each leg to each stud. A hanger and kicker brace the assembly, detailed per architectural drawings, with ceiling or soffit joists sized per schedule. A maximum 18-inch dimension governs the ceiling or soffit drop relative to the structure.
CLG/SOFFIT SEE ARCHI'L (3) #10 SMS, TYP. KICKER PER CEILING OR SOFFIT JOIST PER SCHED. 400S162-43 @ 16" O/C INTERIOR METAL STUDS PER 18" MAX. 12 S0.92 1 S0.91 4 - 4 - PER ARCH'L HANGER PER 4 - CONT. L1 1/2x1 1/2x16 GA. W/ #10 SCREW EACH LEG EACH STUD
