The detail illustrates a beam-to-column and bracing connection framing into a steel column. It features stiffener plates welded to each side of the column web top and bottom, with a 1/2" offset dimension and a working point (WP) at the column center. Diagonal beams and typical diagonal members are connected with bolted gusset or framing connections.
Text on the drawing
BM PER PLAN STL COL PER PLAN WP GRID 1/2" AT PL TO COL CONN SEE C SIM & TYP DIAGONAL BM PER PLAN SEE FOR CONN INFO D D PROVIDE STIFF PL5/8 EA SIDE T&B MAX 1" MAX 1"
