An HSS 4x4x1/4 vertical member connects to a supporting steel beam per plan using four three-quarter-inch diameter bolts with a one-and-a-half-inch typical spacing. A B1 brace connects diagonally to the assembly at a two-to-one slope, with details referenced per sheet S501. An HSS wind girt is secured via a three-quarter-by-eight-inch by one-foot-zero-inch plate and two three-quarter-inch diameter bolts with long slotted holes.
LEVEL 2 2 1 BM PER PLAN SECTION 5A HSS 4x4x1/4 (2) 3/4"Ø BOLTS W/ LONG SLOTTED HOLES SECTION 5B HSS WIND GIRT PER PLAN HSS PER PLAN PL3/4x8x1'-0" B1 BRACE, DETAILS NOT SHOWN PER 11/S501 1 1/2" TYP (4) 3/4"Ø BOLTS EQ EQ 2" TYP
