Metal floor deck spans parallel to a supporting steel beam with a minimum one-inch gap and a continuous finish strip supplied by the steel deck manufacturer. Additional number four reinforcing bars spaced at twelve inches on center run transversely above the assembly. A shear stud is placed directly over the beam flange, omitting the deck beneath the stud location according to note three. Dimensions detail a two-foot six-inch typical span and a zero-foot one-and-one-half-inch minimum clearance.
CONTINUOUS FINISH STRIP BY STEEL DECK SUPPLIER TYPICAL 2' - 6"UON 2' - 6"UON #4@12" ADD'L NO DECK UNDER STUD AT THIS LOCATION SEE NOTE 3 MINIMUM 0' - 1 1/2" GAP 1" MINIMUM AS REQUIRED BY STEEL DECK PROVIDER CL BEAM B DECK SPAN PARALLEL TO BEAM CONTINUOUS FINISH STRIP BY STEEL DECK SUPPLIER TYPICAL 2' - 6"UON 2' - 6"UON #4@12" ADD'L NO DECK UNDER STUD AT THIS LOCATION SEE NOTE 3 MINIMUM 0' - 1 1/2" GAP 1" MINIMUM AS REQUIRED BY STEEL DECK PROVIDER CL BEAM B DECK SPAN PARALLEL TO BEAM
