Structural · S-K3SS9

Double Curtain Jamb Detail

Materials

Concrete Reinforced Concrete

Elements

Beams Walls Foundations / Footings Arches Reinforcing Roof / Floor Openings

Connections

Rebar Splice / Development

About this detail

A double curtain jamb and lintel assembly for a concrete tilt-up wall panel incorporates vertical jamb reinforcing and ties extending continuously from the bottom to the top of the panel, with half of the vertical reinforcement placed on each face of the panel for double-layer conditions. Horizontal lintel reinforcing extends forty bar diameters minimum beyond the edge of the opening or terminates with a ninety-degree hook at the wall edge. Stirrups and hairpins with one-hundred-eighty-degree returns are provided at the top and bottom of the lintel where single bars are required. Architectural wythe connections to the structural wythe are specified by the supplier with a maximum three-quarter-inch reveal or recess.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
