A six-inch diameter safety yellow painted steel pipe with a rounded top is filled with concrete and extends five feet above the finished surface. The pipe is embedded into a concrete retaining wall and footing at the ramp. A layer of thirty-pound felt paper separates the assembly, and paving and slab thicknesses are to be verified on site.
VERIFY PAVING/ SLAB THICKNESS CONCRETE FINISHED SURFACE 30# FELT PAPER SECTION TYP. PLACEMENT EDGE OF WALL 6" DIA. (PAINTED, SAFETY YELLOW) STEEL PIPE W/ROUNDED TOP, FILLED WITH CONCRETE RETAINING CONCRETE WALL AT RAMP 12" TYP. RETAINING CONCRETE WALL AND FOOTING AT RAMP CONCRETE RAMP . 5'-0"
