The drawing illustrates a cross-section and elevation of pipes passing through concrete foundations and footings. Key components include concrete footings, pipe sleeves, and utility pipes with specified minimum and maximum clearances such as 4 inch minimum and 3 foot 0 inch maximum dimensions. An optional pour per contractor is indicated with construction joints.
Text on the drawing
PIPE SLEEVE FOOTING MIN 6" PER CONTRACTOR OPTIONAL POUR MIN 4" 4" MIN 3'-0" MAX
