A wide flange beam per structural drawings supports a continuous 200Z200-97 zee section spaced at sixteen inches on center. A 362T150-54 top track connects to the zee section using four number ten screws, with two screws positioned within three-quarters of an inch of each leg. Cold-formed steel studs designated as 362S162-43 are spaced at sixteen inches on center and engage the top track. A lower structural member receives the framing with three number ten screws at the lap connection.
