A threaded rod hanger suspends loads from a metal deck sized per plan, bearing upon a C3x5 channel spanning three flutes minimum. The threaded rod secures with a standard washer and nut on top of the Unistrut channel. A field weld with a one-eighth inch fillet symbol connects the assembly typically, with a maximum tension limit of two hundred pounds.
METAL DECK PER PLAN C3X5, SPAN 3 FLUTES, MIN THREADED ROD W/ STD WASHER AND NUT ON TOP OF UNISTRUT CHANNEL . T MAX = 200# 1/8 1/8 TYP
