A buckling-restrained braced frame column base plate and gusset plate connection anchors to a concrete footing. The steel column bears on a base plate secured by multiple anchor bolts extending through a concrete slab and into the footing, with a central shear lug pocket and a bottom anchor distribution plate. A buckling-restrained brace connects to a gusset plate welded adjacent to the column base, maintaining a minimum one-inch clearance above the slab. The gusset plate and brace components are designated as protected zones per structural framing specifications.
WP TOP OF FTG TOP OF SLAB BRB FRAME COLUMN PER BRB ELEVATION MIN 1" CLR BOT OF FTG BRB - PER BRB ELEVATIONS and BRBF DWGS - SEE S3.01, S3.02, and S3.2x SERIES SHEETS GUSSET PL PER BRBF DWGS - SEE S3.2X SERIES SHEETS - NOTE: GUSSET PL'S & BRACE COMPONENTS ARE CONSIDERED "PROTECTED ZONES" SEE BRACE FRAME ELEVATION NOTES ON S1-3.01 and S2-3.01 FOR BRACE CONNECTION TYPE NOTE: FOR REMAINDER OF INFO SEE 01 -
