A buckling-restrained brace connects to a structural steel frame column base supported by a concrete footing with anchor bolts and a three-inch non-shrink grout pad. One-half-inch stiffener plates attach to the column flange with five-sixteenths fillet welds typical to the gusset plate and column. The gusset plate thickness is determined per the manufacturer schedule, featuring core stiffener plates and core plate extensions provided by the brace manufacturer. Field welds secure the connection assembly as specified by the manufacturer schedule.
BRB BY MFR FRAME COLUMN PER ELEV BRB CORE STIFF PL & CORE PL EXTENSION BY BRB MFG WP wb Lwb SEE SCHED PER BRB MFR tg, GUSSET PL THICKNESS PER RBR MFR SCHEDULE BRACE CL HOLE AT BOTTOM PER BRB MFR LENGTH FROM WORK POINT TO NEAREST LENGTH OF BRACE BETWEEN OUTERMOST BOLT HOLES AT OPP CONNECTION COL CL 1/2" STIFFENER PLATES, TYP 5/16 TYP TO GUSSET AND COL Wc Lwc SEE SCHED PER BRB MFR 3" NON-SHRINK GROUT FOOTING PER PLAN
