A hollow structural section column supports a half-inch cap plate welded to its top with field welds on three sides. A moment frame beam frames into the column per plan, secured with complete joint penetration welds typical on each side. Non-frame beams frame in on either side with fillet welds specified at quarter-inch sizes.
MOMENT FRAME BEAM PER PLAN CP, TYP CP EA SIDE 5/16 NON-FRAME BEAM PER PLAN 1/2" CAP PL CP BEAM TO CAP PL 1/4 1/4 3 SIDES NON-FRAME BEAM PER PLAN HSSx COL PER PLAN
