An erection pad sits below a concrete slab divided by a three-quarter inch paving joint. Three number five reinforcing bars minimum extend into each side of the slab above. The pad features square dimensions sized per schedule with a three-inch clear cover to internal reinforcement. Slab thickness varies per schedule with a two-inch clearance shown at the top boundary.
