This bridge section indicates the interface between precast concrete elements and steel beams, referencing external connection details for shear tabs and bolts. Polystyrene insulation is specified in the assembly. A Level 3 elevation marker indicates the 37 foot 6 inch level.
NOTES: 1. CONNECTION FROM PRECAST TO STEEL BEAMS BY OTHERS. 2. SEE "TYPICAL STEEL BEAM CONNECTION" FOR SHEAR TAB AND BOLT INFORMATION. 201 LEVEL 3 37' - 6" POLYSTYRENE TYPE TYP, NOTE 1 #4x @ 12" Ld Ld 3/4" = 1'-0" 13 BRIDGE SECTION
