Structural · S-JPJNB

Drift Track and Metal Stud Connection at Roof Beam

Materials

Steel Timber / Wood Metal (misc.)

Elements

Windows Roofs Ceilings Decks Arches Bracing Connections / Plates

Connections

Bracing Connection

About this detail

A drift track connection accommodates vertical building deflection and seismic drifts below a steel roof beam and metal roof deck. Cold-formed metal studs connect to the primary structure via supplier-provided gravity connections, with an angle brace tying into the steel beam above. A horizontal drift joint is incorporated in the building skin at the window head, coordinated with architectural requirements. An offset dimension of six inches maximum governs the angle brace configuration.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
