A hollow structural section steel column connects to a concrete spread footing or plinth via a bearing plate and anchor bolts. Two three-quarter-inch diameter machine bolts with standard washers secure the column, with bolts recessed one inch. A three-quarter-inch bearing plate matching the column dimensions rests on an HSS pipe support above the concrete footing. A slab on grade features an optional blockout with a half-inch gap filled with sealant per architectural specifications. Reinforcing includes number five bars on each side of the footing.
GRID T.O.F. OPTIONAL BLOCKOUT FOR COL. PLACEMENT (ALIGN CORNERS TO C.J.) C.J. - TYP. 2'-0" MIN. #5 EA. SIDE 1 1/2" 3 1/2" 6" HSS2.5x0.25 - PROVIDE 2¾" MAX. HOLE IN GL. COL. GL. COL. S.O.G. FOR OPTIONAL SLAB BLOCKOUT - SEE (2) 3/4". M.B. W/ STD WASHERS - RECESS BOLTS 1" BRG - 3/4" - MATCH DIM. OF COL. HSS PIPE 1/2" 1/4 SPREAD FTG SHOWN - CONC. PLINTH WHERE OCCURS FOR DETAILS & CALLOUTS IN COMMON SEE 2 S3.02 3 S3.02 1/2" GAP W/ SEALANT PER ARCH. 6" 4" 1 1
