An insulated precast concrete wall panel bears against the building structure, featuring a one-and-a-half-inch gap and a maximum six-inch dimension at the floor level. The assembly connects to a wide-flange steel beam supporting a concrete slab on metal deck, reinforced with a four-by-four-by-three-eighths-inch angle kicker on each panel bearing point. One-half-inch Grade 50 full-depth stiffener plates are welded to each side of the web directly below the panel bearing point using a quarter-inch fillet weld. A hollow structural section beam provides lateral out-of-plane attachment lower down on the panel. The general contractor must coordinate exact locations with the precast manufacturer and steel fabricator.
GRID TOSC EL REF PLAN GLAZING REF ARCH TYP BO PANEL EL REF ARCH TO PANEL EL REF ARCH CONCRETE SLAB ON METAL DECK REF PLAN REF PLAN 1 1/2" GAP INSULATED PRECAST PANEL BY PRECASTER HSS BEAM REF PLAN 1" TOS EL REF PLAN PRECAST PANEL LATERAL (OUT-OF-PLANE) ONLY ATTACHMENT TO MAIN STRUCTURE BY PRECAST PANEL MFR PRECAST PANEL BEARING ATTACHMENT & EMBEDS BY PRECAST PANEL MFR 1/2" FULL DEPTH STIFFENER PL (GRADE 50) EA SIDE OF WEB AT PANEL BEARING POINT 1/4 TYP NOTE: REFER TO DETAIL "A" FOR INFO NOT SHOWN PROVIDE FULL DEPTH STIFFENER PLATES DIRECTLY BELOW PRECAST PANEL BEARING ATTACHMENT. GC TO COORDINATE EXACT LOCATION WITH PRECASTER & STEEL FABRICATOR. L4x4x3/8 KICKER AT EA PANEL BEARING POINT PLAN REF MAX 6"
