Steel columns and beams support a profiled steel roof deck with welded connections. A deck bearing angle, specified as an L5x3x1/4 with the toe down, is welded to the beam web. Vertical sleeve plates measuring 8 inches by 3/8 inch by 4 inches are attached to each side with welds. Additional structural elements include welded connections, complete joint penetration welds, and diagonal bracing plates with bolted gusset connections.
STEEL COLUMN STEEL BEAM STEEL COLUMN SF601 D1 TYP 8"x3/8"x4" VERTICAL SLEEVE PLATE EA SIDE STEEL ROOF DECK STEEL ROOF DECK 1/4 1/4 3/16 3/16 3-12 3/16 L5x3x1/4 (DECK BEARING ANGLE (TOE DOWN) WELD TO BEAM WEB 1" CJP SF502 C3
