A supported steel beam connects to a supporting steel beam utilizing a stiffener plate sized per table E. The connection incorporates a complete joint penetration weld at the top flange and five-sixteenths inch fillet welds typical along the web and plate intersections. A note specifies that the built-up beam weld length equals the plate length plus six inches. Four bolts fasten the framing web connection with a three-inch on-center typical spacing.
SECT SECT TABLE E 11 1/4" SECTION 10" SEE "TABLE E" FOR PLATE SIZE SEE NOTE 1 SUPT BM CJP 5/16 5/16 SEE NOTE 3 "W" "W" LENGTH OF WELD FOR BU BM = PL LENGTH + 6" 2" STIFFENER PLATE, SEE "TABLE E" SEE NOTE 1 2" 2" 1 1/2" 9" TYP 4 3/4" 2" 3/4" MAX 1/2" TYP 5/16 5/16 PL LENGTH 3" OC TYP 3' - 0" MAX
