A pipe penetration passes through a concrete wall footing using a metal sleeve with a diameter equal to the pipe diameter plus two inches. A collar is provided around the pipe to keep dirt out of the sleeve. The installation requires a minimum clearance between adjacent pipe sleeves of three and a half inches or three times the pipe diameter, whichever is greater. The general contractor is responsible for coordinating the exact depth and location of the pipe, with dimension "D" not to exceed eight inches.
2 1 MAXIMUM EXTENT OF EXCAVATION PROVIDE COLLAR AROUND PIPE TO KEEP DIRT OUT OF SLEEVE WALL FOOTING OPTIONAL CONST JT METAL SLEEVE DIA = PIPE DIA + 2" 3D OR 6" NOTES: 1. STEP FOOTING PER TYPICAL STEPPED FOOTING DETAIL AS REQUIRED TO SATISFY THESE CONDITIONS. 2. GENERAL CONTRACTOR TO COORDINATE EXACT DEPTH AND LOCATION OF PIPE. 3. "D" SHALL NOT EXCEED 8". (WHICHEVER IS GREATER) CLR MIN BETWEEN ADJACENT PIPE SLEEVES 3 1/2" MIN MIN 1'-0" PASS THRU FTG NO PIPES SHALL 3'-0" MAX ELEVATION SECTION MIN 9" MIN 6" D MIN 4"
