A top braced frame connection occurs at a hollow structural section column framing into a beam. The assembly incorporates a brace member intersecting at a work point with connection plates welded to the structural framing. Fillet welds of five-sixteenths and one-quarter inch are specified at the structural intersections. A quarter-inch stiffener plate is provided where no perpendicular beam occurs. Additional connection requirements are referenced to coordinate sheets.
BEAM PER PLAN (1/4" SLOPE) COLUMN PER ELEVATION CL BRACE BRACE PER ELEVATION WP CL BEAM CL COLUMN 5/16 HSS COL 7" @ NOTE: FOR ADDITIONAL INFORMATION, SEE . / 4 S331 FLOOR CONN PER 11/S501 @ PERP BM (1/4" STIFFENER PL @ NO BM) 1/4 1/4 NTS 5 TOP BRACED FRAME CONNECTION (HSS COLUMN)
