Cold-formed steel soffit joists are supported by metal studs and suspended from the overhead structure per plan, incorporating diagonal kickers spaced at forty-eight inches on center and eight feet on center for lateral bracing. Vertical metal studs tie into the ceiling or floor assembly above using specified connection details, while the lower framing supports finish materials for the suspended soffit. The assembly utilizes cold-formed steel framing members and structural steel support elements sized according to structural schedules.
FINISH METAL STUDS PER SUSPENDED SOFFIT PER ARCH KICKER PER SOFFIT JOIST PER SCHED BEAM PER PLAN METAL STUDS PER OR 09A - 09A - 12 S6.72 KICKER PER @48" O/C 16 - KICKER PER @8´-0" O/C 12 S6.72 @48" O/C 01 S6.71A OR 01 S6.71B 03 - 13A S6.72 01 S6.71A 01 S6.71B 18 S6.72
