A wide-flange steel column intersects with framing steel beams and a structural brace at a grid line working point. A three-quarter-inch thick steel cap plate sits atop the column below framing steel beams connected by bolted shear tabs. A half-inch thick ASTM A572 Grade 50 gusset plate connects to the brace and sits upon a three-quarter-inch by six-inch bearing plate fastened with seven-eighth-inch diameter A325 bolts at five inches on center. Five-sixteenth-inch fillet welds secure the gusset plate assembly, while quarter-inch fillet welds attach the cap plate and column components. The assembly provides rigid lateral bracing support at the column-beam intersection.
GRID STL BM W.P. 4" 5" 3" MIN. 1" STL BM STL COL. STL CAP ' 3/4" 1/4 6" 1/4 1/4 * WF COL. * BRACE BRG ' 3/4"x6" W/ 7/8". A325 @ 5" O.C. ' 1/2 A572 GR. 50 5/16 5/16 5/16 5/16
