An elevator attachment plate connects to an HSS14x6 hollow structural section column, requiring coordination with architectural and elevator drawings for exact positioning. The attachment plate is referenced to a typical detail on the same sheet for secure connection to the HSS column per plan.
HSS14x6, REF. PLAN PLATE FOR ELEVATOR ATTACHMENT. COORD. LOCATION W/ ARCH. AND ELEVATOR DWGS. REF. TYP. DETAIL ON THIS SHEET FOR ATTACHMENT TO HSS 2 S2.7 _____
