Spatial relationship and clearance limits between underground utility pipes and building foundations. The pipe trench must be located sufficiently away from the footing to prevent undermining, maintaining a two-to-one slope line drawn from the bottom edge of the footing. Pipes passing near the footing require a metal sleeve with an inside diameter at least two inches greater than the outside diameter of the pipe. Concrete fill must match the width of the footing and span the full width of the trench where specified. Trenching below the footing is prohibited after the footing has been poured.
. MIN. 6" MIN. 4" . BACKFILL PER SPECIFICATIONS GROUND LINE LOCATE PIPE TRENCH SO THAT FOOTING WILL NOT BE UNDERMINED NO EXCAVATION BELOW THIS LINE POUR JOINT 1 FOR PIPES MORE THAN 3'-0" BELOW THE BOTTOM OF THE FOOTING TRENCH MAY BE BACKFILLED WITH COMPACTED FILL PER SPECIFICATIONS. DO NOT TRENCH BELOW FOOTING AFTER FOOTING HAS BEEN POURED. NO PIPE ALLOWED TO PASS THRU THIS PORTION OF FOOTING METAL SLEEVE W/ I.D. 2" GREATER THAN THE O.D. OF THE PIPE PLUMBING OR CONDUIT TO BE HELD AS HIGH AS POSSIBLE CONC. FILL SHALL BE SAME WIDTH AS FOOTING AND FULL WIDTH OF TRENCH. PLACE 1'-6" MIN. 1'-6" MIN. 2" MIN. 1'-6" MIN. 2 . 9" A
