A profiled metal deck bears across a steel beam joist girder with a twelve-gauge metal closure piece supplied by the metal deck manufacturer between joists. The deck is secured with one-half-inch diameter puddle welds at twelve inches on center maximum. A continuous or spaced fillet weld connects the supporting structural elements with sizes indicated by standard weld symbols. Dimensional clearances and variable dimensions are coordinated with architectural drawings.
NOTE: MIRROR SHAPE AT ENDS OF WALL AS REQ'D 1/8 2-12 1/8 2-12 VARIES SEE ARCH. METAL DECK TO JOIST GIRDER STL BM 12 GA. BY MTL DECK MFR BTWN JOISTS 6" 2" 1/2" PUDDLE WELD @ 12" O.C. MAX.
