The assembly features a hollow structural section wind girt supporting exterior metal stud framing with a horizontal drift joint in the skin. A continuous L3x3x1/4 angle welded with a quarter-inch fillet weld at twelve-inch spacing connects the framing components. A bent plate per detail 7/SE601 bridges the concrete over metal deck floor slab to the exterior wall. A steel beam supports the floor slab where it occurs, featuring a bolted connection to the wind girt. A drift track connection accommodates vertical deflection and wind or seismic drifts noted in the general structural notes.
HSS WIND GIRT MTL STUD BY SUPPLIER EXTERIOR FINISH, SEE ARCH DRIFT TRACK CONNECTION TO ACCOMODATE VERT DEFLECTION AND WIND/SEISMIC DRIFTS NOTED IN THE GSN MTL STUD TO BEAR ON HSS GIRT, CONN TO STRUCT BY SUPPLIER HORIZONTAL DRIFT JOINT IN THE SKIN AT GIRT. SEE ARCH FOR MORE INFORMATION STL BM (WHERE OCCURS) CONC OVER MTL DECK BENT PL PER DET / (7 SE601) BTWN BM L3X3X1/4 x CONT 1/4 3-12 1/4 3-12 5 SE602
