A hollow structural section beam frames into a wide flange beam supported by a three-eighths inch plate welded with a five-sixteenths inch fillet weld. Fasteners secure the connection through the plate to the framing members. Unnotched information is referenced back to detail five on sheet S5-210.
5 S5-210 A - NOTES: 1. FOR INFORMATION NOT NOTED SEE CL CL PL 3/8 WIDE FLANGE BEAM WIDE FLANGE BEAM SEE PLAN A SECTION 5/16
