An open web steel joist connects flush to the web of a structural steel beam using a manufacturer-provided flush connection assembly. A three-eighths-inch stiffener plate is welded to the beam web, with its location and connection coordinated with the joist supplier. The bolt number and size are coordinated directly with the joist manufacturer. Metal roof deck bears across the top chord of the joist and the steel beam flange.
COORD BOLT NUMBER AND SIZE W/ JST MFR OPEN WEB STL JST W/ FLUSH CONNECTION BY MANUFACTURER STL BM WEB PL BY JST SUPPLIER 3/8" STIFF PL COORDINATE LOCATION AND CONNECTION W/ JOIST SUPPLIER 13 S701 MTL ROOF DECK 1/4
