Steel beams frame into a central column with continuity plates aligning at the top flange elevations. Bolted shear tabs connect the beam webs to the column flanges, using sizing specified in the structural schedule plus one-sixteenth inch. The top of steel elevation is maintained with specific flange offset dimensions designated as TF1 and TF2. Additional bolt rows in the connection are configured per the structural plans.
TOP OF STEEL SHOWN ON PLAN THUS: CONTINUITY PLATES SEE TYP DETAIL, USE LARGER OF TF1 OR TF2 TYP M SEE SCHED +1/16 TF1 TF2 NUMBER AND SIZE OF BOLTS IN 1ST ROW SEE NOTE 2 NUMBER OF ADDITIONAL BOLTS IN 2ND ROW SEE PLAN
