A structural steel railing post extends upward with a base plate anchored above a wide-flange beam. The adjacent metal grating is notched to fit around the rail post base plate as required. A toe kick is positioned at the base of the railing assembly. The top of steel elevation is coordinated per plan.
RAILING, S.A.D. FOR EXTENT. SEE , FOR ADD'L INFO. a 1 1/2" TYP. WF BEAM, SEE PLAN TOE KICK, SEE , FOR ADD'L INFO. c GRATING BEYOND, SEE PLAN NOTCH AROUND RAIL POST BASE PLATE, AS REQ'D T.O. STEEL SEE PLAN
