A structural steel column is welded to a base plate with a five-sixteenths inch fillet weld and secured to a concrete foundation by four three-quarter inch diameter anchor rods with a one-foot minimum embedment. Non-shrink grout is placed beneath the base plate, and the contractor must hold the base plate rigidly in place during the grouting process. Anchor rods are tightened snug tight with threads scored to prevent loosening.
TOC EL (4) 3/4" DIA AR W/ 1'-0" MIN EMBED FIN COL END & BASE PL PER AISC NON-SHRINK GROUT SEE NOTE 4 5/16 NOTES: 1. TIGHTEN ANCHOR RODS SNUG TIGHT AND SCORE ROD THREADS TO PREVENT LOOSENING. ELEVATION PLAN STL COL, SEE PLAN FOR SIZE CL COL CONTRACTOR SHALL HOLD BASE PLATE RIGIDLY IN PLACE WHILE GROUTING BASE PL TxWxL SEE PLAN FOR SIZE CL COL 1" 12" 10" TYP 1 1/2" EQ EQ TYP 1 1/2" EQ EQ 1 1/2" "L" "W" "T"
