Three structural details illustrate angle supports and framing connections at columns and beams. Detail A shows an L3x3x3/16 support angle configured with a beam and column, incorporating a top flange cover plate where required and 3/16 typical fillet welds. Details B and C display one-way column conditions with L3x2x1/4 long-leg-horizontal angles supporting metal deck span directions adjacent to column flanges and beams. General notes specify 16-gauge metal filler requirements, omission criteria based on dimensions D1 and D2, metal deck cutting procedures, perimeter column applicability, and American Welding Society minimum weld size governances.
