This structural detail establishes the lap splice length, offset limits, and contact spacing requirements for beam and column reinforcing bars. Top and bottom reinforcement bars are shown lapping with specified development lengths designated as 'Ld' or twelve times the bar diameter with a twelve-inch minimum. Bars are wired in contact or spaced with a maximum one-and-one-half-inch clear distance. Column and boundary elements follow corresponding vertical offset profiles.
BOUNDARY, COLUMN AND BEAM REINFORCING SPLICE DETAIL A COLUMN *1 1/2" OR WIRED IN CONTACT BOTTOM REINF 1 MAX 12 6 TOP REINF 1 MAX "L" 12" MIN 12d OR * * "Ld" 12" MIN 12d OR d 1 1/2" MIN BEAM
