A pipe penetrates the bottom track with a maximum clearance dimension of nine inches on either side. A Simpson ST6215 strap secures the assembly with three number ten screws at each end on each track flange.
BOTTOM TRACK PENETRATION DETAIL 3D 9" MAX. 9" MAX. PIPE BOTTOM TRACK SIMPSON ST6215 STRAP W/ (3) # 10 SCREWS EACH END EACH TRACK FLANGE
