Wood posts connect to wood beams sized per plans using various Simpson post and beam caps. Detail B shows a Simpson CC column cap supporting a wood beam over a wood post with through bolts. Detail A utilizes a Simpson ECC side-mount cap for an edge condition. Detail C employs a Simpson CCT bracket for continuous beam conditions. Detail D uses a Simpson ECCLL bracket for eccentric post and beam framing.
