Truss girder connection to a precast concrete wall panel. The assembly consists of three 3/8-inch thick gusset plates welded to an embed plate with a 5/16-inch fillet weld. The embed plate anchors into the precast concrete wall panel, which contains reinforcement sized per the panel elevation. The truss girder aligns with the center line of the connection, with the gusset plates spaced at 4-inch intervals from the center line. Detail 17.
Text on the drawing
2" 2" PLAN VIEW (3) 3/8" GUSSET PL 4" C OF TRUSS GIRDER L 4" 8" 8" 17 - 5/16 PRECAST CONCRETE WALL PANEL REINFORCEMENT SEE PANEL ELEVATION 4"
