A six-inch-by-six-inch hollow structural section with a one-half-inch wall thickness features two four-inch-diameter holes centered at the rain leaders. The rain leader is coordinated per the architectural drawings. The centerlines of the hollow structural section, the drilled hole, and the rain leader align vertically, spaced three inches apart.
HSS PER PLAN, TYP RAIN LEADER PER ARCH, TYP NOTES: 1. SEE FOR TYP HSS CONNECTIONS AT MEDITATION HALL. E/S5.03 CL MEDITATION HALL HSS 6x6x1/2 W/ (2) 4"Ø HOLES CENTERED AT RAIN LEADERS 3" 3" CL HSS CL HOLE CL RAIN LEADER
