An HSS column base connects to a thick embed plate anchored by multiple anchor bolts extending downward through a concrete assembly. A two-inch layer of non-shrink grout sits beneath the base plate to transfer loads evenly. Side connection plates welded with five-sixteenths fillet welds secure an adjoining HSS member using two seven-eighths diameter high-strength bolts on each side. Standard bolt holes are provided alongside one-and-a-half-inch grout holes within the embed plate assembly.
2" NON-SHRINK GROUT W8 WORK POINT FINISHED FLOOR EMBED PL 1-1/4" CONNECTING ALL AB, STD BOLT HOLES [w/ (2) 1-1/2" GROUT HOLES] HSS6x4 8" 8" 12 S7.3 PL 1/2x7" ES w/ (2)-7/8" ⌀ HSB NOTE: FOR DETAILS NOT SHOWN OR NOTED, SEE 8 S7.3 SIM 6" 5/16 TYP
