This structural detail outlines a four-inch thick concrete slab featuring control joints spaced across the assembly. Reinforcing is scheduled per the general structural notes. The top of concrete is established at one hundred feet and zero inches unless noted otherwise.
4" THICK CONCRETE SLAB REINFORCING PER GSN TOC = 100'-0" (UNO) C.J. C.J. C.J. C.J. 4 S501 _____ TYP 4 S501 _____ TYP
