A structural steel beam connects to a support via a half-inch by seven-inch Grade 50 support plate featuring two rows of bolts. The beam is coped as required with a maximum one-half inch clearance from the support face. Five-sixteenth inch fillet welds secure the plate to the support assembly.
2 1/2" 3" 1 1/2" BM PER PLAN SUPPORT PL1/2X7 GR 50 W/ 2 ROWS OF BOLTS 1/2" MAX CL BM COPE IF REQD TYP "Z" TYP 5/16 5/16
