Steel beams frame into a steel column and a beam-to-beam connection with a full-height stiffener using single shear plates and bolted connections. The single plates attach the steel beams to the support elements with specific vertical bolt spacings and edge distances. A one-inch clearance is maintained between the framing beam and the column flange or stiffener plate.
STEEL BEAM STEEL BEAM STEEL BEAM STEEL BEAM FULL HEIGHT SINGLE PLATE SINGLE PLATE NOTE 2 NOTE 2 STEEL COLUMN BEAM TO BEAM CONNECTION AT FULL HEIGHT STIFFENER BEAM TO COLUMN CONNECTION Leh Leh Lev 3" 3" Lev 1" Lev S S Lev Leh Leh 1"
