A supported steel beam connects to a supporting beam web via a full depth welded shear plate designated XW with a three-quarters inch maximum clearance. A full depth stiffener plate is welded to the supporting beam with quarter-inch fillets on three sides. Erection bolts are provided as required for initial assembly. A five-sixteenths inch field weld secures the shear plate to the supported beam.
FULL DEPTH STIFFENER PL w/ ERECTION BOLTS AS REQ'D. FULL DEPTH WELDED SHEAR PL DESIGNATED XW 5/16 1/4 1/4 (3) SIDES NOTES: 1. FOR SCHEDULE REF. 3/S601. 2. FOR INFORMATION NOT SHOWN ON AND REFERENCE CONDITION . 3. FOR WELDS AT SKEWED CONNECTIONS REF. 8/S601. X XS XW 3/4" MAX.
