Reinforcement configuration for a typical concrete coupling beam designated as Type 1. Longitudinal reinforcement bar layers, stirrup spacing labeled as stirrups S1, and development embed lengths denoted as Lt. Additional dimensions specify a 2-inch typical clearance alongside overall depth and embed zones.
REINF HEF REINF "a" 24" DEPTH 19" 19" 24" "TYP COUPLING BM, TYPE 1 SECTION" 2" TYP EMBED EMBED Lt Lt 49" STIRRUPS S1
