S-HVF9F — Typical Steel Beam Connection to Steel Column

Structural · S-HVF9F

Typical Steel Beam Connection to Steel Column

Materials

Elements

Columns Beams Decks Connections / Plates

About this detail

Steel floor beams connect to a central steel column supporting a steel deck above. A steel cap plate caps the top of the column. A one-eighth-inch by continuous bent plate spans between joists below the steel deck.

JK1RSB10 STEEL CAP PLATE STEEL COLUMN STEEL DECK TYP STEEL BEAM STEEL BEAM STEEL BEAM 1/8" x CONT BENT PLATE BTWN JOISTS

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
