A structural steel braced frame connection details the intersection of a column centerline and a beam centerline with a work point designating the brace intersection. Continuity plates are positioned at the top and bottom flanges of the beam aligning with the column web. Gusset plates connect diagonal braces to the structural members with bolted connections.
WP CL COLUMN CL BEAM CONTINUITY PLATES AT TOP & BOTTOM FLANGE SEE TYPICAL BRACED FRAME CONTINUITY PLATES TYPICAL
