A typical diagonal brace connection frames into a truss bottom chord member. Stiffener plates matching the brace flange thickness are welded inside the chord on each side with three-eighths inch fillet welds typical. Complete joint penetration welds are specified at the diagonal member connections to the chord. The assembly aligns with a grid work point and references a typical welded truss chord splice detail.
GRID SPLICE STIFFENER PL ES, TYP MATCH BRACE FLG THK ES, TYP 3/8 3/8 CJP TYP AT BOTTOM CHORD NOTES: 1. REFER TO "TYPICAL WELDED TRUSS CHORD SPLICE DETAIL". WP ℄ CHORD ℄ DIAG ℄ DIAG SEE ELEVATION 3 18 TYPICAL DIAGONAL TO CHORD CONNECTION
