A hollow structural section girt spans horizontally from a structural steel column, secured via a girt bracket. A support angle attached below the girt carries the wall panel or louver assembly, with legs coped as required for bolted connections and clearance. The wall panel aligns outward from the gridline at a specified dimension, with components coordinated between architectural drawings and structural schedules.
3" 2" 2" 2'-10" GRID COL PER SCHED WALL PANEL PER ARCH DWG A-351 - A-353 GIRT BRACKET PER S-560 TRLNT PANEL OR LOUVER PER ARCH DWG A-201 & A-202 GRID HSS GIRT PER EL COPE AS REQD FOR BOLT CONN SUPT ANGLE BY TRLNT PANEL OR LOUVER DSGNR, COPE HORIZ LEG AS REQD 1 3 5 2 4
