This connection details a steel joist bearing onto a tilt-up concrete wall panel using a steel ledger sized per plan or schedule. A four-by-four-by-three-quarters-inch by one-foot-zero-inch bearing angle supports K-series joists, while a six-by-four-by-seven-eighths-inch by one-foot-zero-inch bearing angle supports long-span (LH/LLH) joists. Boundary fasteners secure the assembly to the concrete panel per plan. The joist manufacturer designs the seat to transfer axial loads as required, with a wood nailer held back accordingly and welded connections to the ledger or ledger splice plate.
WS03-02 070911 4 1 STEEL LEDGER PER PLAN OR SCHEDULE 2 L4x4x3/4 x 1'-0" BEARING ANGLE AT K JOIST. L6x4x7/8 x 1'-0" LLH BEARING ANGLE AT LH JOIST 3 BOUNDARY FASTENERS PER PLAN OR SCHEDULE 4 JOIST MFR. TO DESIGN SEAT TO TRANSFER AXIAL LOAD PER PLAN 5 HOLD BACK NAILER AS REQUIRED 6 TO LEDGER (OR LEDGER SPLICE PLATE AS OCCURS) A. PANEL REINFORCING NOT SHOWN FOR CLARITY B. DESIGN BEARING SHOE FOR SHORT-BEARING CONDITION, AS OCCURS 1/4 6 1 1/4 2 1/4 2 5 2 3 NO SCALE SUBPURLIN AT STEEL JOIST 209
